Description
This 5″ two-way plastic speaker has an impedance of 8 Ω and supports both constant-impedance and adjustable constant voltage operation, ensuring easy compatibility with a wide range of amplifiers. The woofer features a 5-inch PP + MICA composite cone with a rubber surround, delivering a solid and powerful low-frequency response. The tweeter is fitted with a 25 mm silk dome diaphragm, producing clear, bright high-frequency reproduction. Supplied with a universal adjustable mounting bracket, the speaker allows for quick and flexible installation and is suitable for a wide range of audio applications, including home cinemas, commercial background music systems, conference installations, hotels and other public spaces.
| MS-502BOX-T20 | |
|---|---|
| Model | 2-way |
| Woofer | 5.25" Mica Composite Cone |
| Tweeter | 0.78" Silk Tweeter |
| Rated Power handling | 40 Watts |
| Max power handling | 80 Watts |
| Frequency response | 125-20K Hz |
| Sensitivity | 86dB |
| Phys. Dimension | 256.5L×176.5W×169H MM |
| Cutout Requirements | 68L×53.2W MM |
